Imaging systems / OEM-ready

Camera modules, indexed like a datasheet.

Browse the Pure-I catalogue of spectral and high-resolution camera families — VIS, NIR, SWIR, MWIR — engineered for integration into medical, life-science, and industrial-inspection products. Every card below links to a procurement-grade PDF spec sheet.

Request a Demo Download SDK 4.0 brief
  • 4Camera families
  • 9Spectral bands (VIS → MWIR)
  • 38Medical-device OEM integrations
  • 84,000 hDocumented MTBF, field-deployed

§ 00 — Catalogue index

Select by spectral band.

Jump straight to the wavelength range relevant to your integration. Each anchor scrolls to the family datasheet card below.

§ 01 — Family datasheets

OEM-ready camera modules.

Four families, one SDK. Each module ships with a procurement-grade PDF datasheet covering optical, electrical, mechanical, and regulatory specs.

  • HALO-9 snapshot hyperspectral camera module render

    01 / HALO-9

    HALO-9 — 9-band snapshot hyperspectral.

    Patented on-chip mosaic captures 9 spectral bands simultaneously. 0.3 nm resolution, sub-$15K, the widest in-frame band count of any module in its class.

    Sensor
    CMOS, snapshot mosaic
    Bands
    9 (VIS – NIR)
    Interface
    USB3 Vision / GenICam
    Download spec sheet (PDF) Tech note →

    VIS · 400–700 nm · 0.3 nm

  • NOVA-X high-resolution area-scan camera module render

    02 / NOVA-X

    NOVA-X — high-resolution NIR area scan.

    20 MP global-shutter CMOS optimized for machine-vision inspection. Trigger-to-image latency under 4 µs, PoE+ power, IP67 sealed housing.

    Resolution
    20 MP (5472 × 3648)
    Frame rate
    60 fps @ 8-bit
    Interface
    GigE Vision / PoE+
    Download spec sheet (PDF) Application note →

    NIR · 700–1100 nm · 60 fps

  • IRIS-700 extended InGaAs SWIR line-scan camera render

    03 / IRIS-700

    IRIS-700 — extended InGaAs SWIR line.

    Line-scan SWIR module for food-sort, semiconductor, and pharmaceutical inspection. 1024-pixel linear array, vacuum-sealed TEC-cooled sensor window.

    Sensor
    InGaAs linear, 1024 px
    Line rate
    up to 40 kHz
    Interface
    Camera Link HS
    Download spec sheet (PDF) Application note →

    SWIR · 900–1700 nm · 40 kHz

  • KAIROS cooled MWIR thermal camera module render

    04 / KAIROS

    KAIROS — cooled MWIR thermal module.

    Stirling-cooled InSb detector for radiometric thermography and gas-imaging payloads. NETD < 18 mK, radiometric calibration traceable to NIST.

    Sensor
    InSb, 640 × 512
    NETD
    < 18 mK @ 300 K
    Interface
    CoaXPress / SDK 4.0
    Download spec sheet (PDF) Tech note →

    MWIR · 3–5 µm · <18 mK NETD

§ 02 — Comparison sheet

Side-by-side technical comparison.

Resolve HALO-9 vs. NOVA-X vs. IRIS-700 vs. KAIROS on the dimensions engineers actually evaluate during BOM selection.

Parameter 01HALO-9VIS · Hyperspectral 02NOVA-XNIR · Area scan 03IRIS-700SWIR · Line scan 04KAIROSMWIR · Thermal
Spectral range 400 – 700 nm 700 – 1100 nm 900 – 1700 nm 3 – 5 µm
Sensor type CMOS, snapshot mosaic CMOS, global shutter InGaAs linear array InSb, Stirling-cooled
Resolution 2048 × 2048 (×9 bands) 5472 × 3648 (20 MP) 1024 × 1 line 640 × 512
Frame / line rate up to 120 fps (cube) 60 fps 40 kHz line rate 120 fps
Interface USB3 Vision / GenICam GigE Vision / PoE+ Camera Link HS CoaXPress
SDK 4.0 support Full · single API Full · single API Full · single API Full · single API
Compliance CE · RoHS · ISO 13485 CE · RoHS · IP67 CE · RoHS · ITAR-ready CE · RoHS · ITAR
Typical lead time 3 weeks 2 weeks 4 weeks 6 weeks

Full mechanical drawings, MTBF reports, and EMC test summaries included with the procurement package. Request access →

§ 03 — Field record

Field-proven in production.

  • 4,200+

    Camera modules deployed in active production environments worldwide

    Source · internal shipment log, FY2024

  • 22

    Countries with documented field installations and on-site service coverage

    Source · field engineering, FY2024

  • 38

    Medical-device OEMs shipping FDA-cleared systems built on Pure-I modules since 2014

    Source · OEM reference list

  • 84,000 h

    Mean time between failures, documented across deployed SWIR and MWIR units

    Source · reliability report, 2024

  • ISO 13485
  • CE
  • RoHS
  • ITAR
  • SOC 2 Type II
  • Class 1000 cleanroom build

§ 04 — Next step

Bring your optical stack. We'll bring a live demo.

Tell us your application, integration timeline, and spectral band — a Pure-I applications engineer will schedule a live demo or send a benchmark evaluation report against your reference sample within five business days.

  • Live remote demo on your sample, NDA available
  • Benchmark evaluation report in 5 business days
  • Procurement-grade PDF datasheets on request
  • SOC 2 Type II · ISO 13485 compliant data handling
Request a Demo Download SDK 4.0 brief

Or talk to engineering directly:
[email protected] · +1 (585) 410-9082
